Hykon's Hybrid Inverter combines solar charging, battery backup and grid power in one unit. It works with both lead-acid and lithium-ion batteries and comes in single-phase (5kVA) and three-phase (5kVA and 10kVA) versions. With cloud-based monitoring and BIS certification, it is built for reliable, efficient power.

Models available

• Single phase: GTSI-0506K1P (5kVA)
• Three phase: GTSI-0506K3P (5kVA) and GTSI-1012K3P (10kVA)

Highlights

• BIS certified
• Easy to service
• Cloud-based monitoring
• 5-year warranty (terms and conditions apply)

Key features: single phase (5kVA)

• Up to 10 units can be connected in parallel
• Remote monitoring and control
• Designed for lead-acid and lithium batteries
• Minimal losses and maximum efficiency
• 100% unbalanced output per phase, with a maximum of 50% of rated power per phase

Key features: three phase (5kVA and 10kVA)

• Colourful touch LCD
• AC coupling to retrofit an existing solar system
• Up to 16 units in parallel in off-grid mode
• Multiple modes for battery and profile settings
• Works with lithium and lead-acid batteries

Why choose the Hykon Hybrid Inverter

• High efficiency: Up to 97.6% maximum efficiency and over 99% MPPT efficiency.
• Flexible battery support: Lithium-ion batteries are charged by adapting to the battery's BMS (Battery Management System).
• Built for tough conditions: IP65 rating, operating temperature from -40°C to 60°C (derating above 45°C), and humidity up to 100%.
• Strong surge capacity: Peak power of 2 times the rated power for 10 seconds.
• Stay connected: RS485/RS232/CAN communication, with GPRS/WiFi remote monitoring.

Protection features
PV polarity reverse connection protection, AC output overcurrent protection, thermal protection, AC output overvoltage protection, AC output short-circuit protection, island protection monitoring, battery power polarity protection and built-in SPD. Surge protection is Type II on both the DC and AC sides.
